Processor
Processor manufacturer: AMD
Processor socket: Socket AM4
Compatible processor series: 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 7
Maximum number of SMP processors: 1
Features
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard chipset: AMD B550
Motherboard form factor: ATX
Memory
Supported memory clock speeds: 3466, 4133, 4000, 2400, 4333, 3200, 4266, 2133 MHz, 4200, 3866, 3800, 4466, 2667, 3733, 4400, 2933, 3600, 4533 MHz
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Number of memory slots: 4
Maximum internal memory: 128 GB
Memory slots type: DIMM
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Wake-on-LAN ready: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Internal I/O
Peripheral (Molex) power connectors (4-pin): 4
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Audio connector: Yes
USB 2.0 connectors: 2
Front panel audio connector: Yes
Number of COM connectors: 1
BIOS
BIOS type: UEFI
Packaging content
Drivers included: Yes
Storage controllers
RAID levels: 0, 10, 1
Supported storage drive interfaces: M.2, Serial ATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 1
