Processor
Processor socket: Socket AM4
Processor manufacturer: AMD
Compatible processor series: 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 7
Maximum number of SMP processors: 1
Graphics
Graphics card: Radeon Vega
HDCP: Yes
On-board graphics card: Yes
Graphics card family: AMD
DirectX version: 12.0
Features
Motherboard chipset: AMD B550
Audio chip: Realtek ALC1200
Motherboard chipset family: AMD
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Memory
Unbuffered memory: Yes
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 3200, 2933, 3600, 2667, 3733, 4400, 3866, 3466, 4133, 4000, 4333, 2400, 4533 MHz, 3800, 4466, 4266, 2133, 4200
Maximum internal memory: 128 GB
Number of memory slots: 4
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
LAN controller: Realtek RTL8111H
Wake-on-LAN ready: Yes
Wi-Fi: No
Internal I/O
USB 2.0 connectors: 4
Number of COM connectors: 1
CPU fan connector: Yes
Number of SATA III connectors: 6
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Peripheral (Molex) power connectors (4-pin): 1
Front panel audio connector: Yes
12V power connector: Yes
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Drivers included: Yes
Storage controllers
Supported storage drive interfaces: M.2, Serial ATA III
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Microphone in: Yes
PS/2 ports quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
