Processor
Compatible processor series: 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 7
Processor manufacturer: AMD
Maximum number of SMP processors: 1
Processor socket: Socket AM4
Graphics
Graphics card: Radeon Vega
DirectX version: 12.0
HDCP: Yes
On-board graphics card: Yes
Graphics card family: AMD
Features
Motherboard form factor: mini ITX
Motherboard chipset: AMD B550
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Audio chip: Realtek ALC887
Memory
Unbuffered memory: Yes
Supported memory clock speeds: 2667, 3733, 4400, 2133, 2400, 4133 MHz, 4000, 4333, 4600, 3866, 3466, 2933, 3600, 3200 MHz, 4266, 4200, 3800, 4466, 4533
Maximum internal memory: 64 GB
Memory channels: Dual-channel
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Number of memory slots: 2
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Wake-on-LAN ready: Yes
Bluetooth: Yes
LAN controller: Realtek RTL8111H
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11a, 802.11g, 802.11b
Ethernet LAN: Yes
Wi-Fi: Yes
Ethernet interface type: Gigabit Ethernet
Bluetooth version: 4.2
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
CPU fan connector: Yes
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Drivers included: Yes
Storage controllers
Supported storage drive interfaces: M.2, Serial ATA III
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
HDMI ports quantity: 1
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
