Processor
Compatible processor series: AMD Ryzen™ 3, AMD Ryzen™ 5
Processor manufacturer: AMD
Processor socket: Socket AM5
Maximum number of SMP processors: 1
Graphics
On-board graphics card model: Aspeed AST2600
Features
PC health monitoring: CPU, Fan, Voltage
Motherboard form factor: micro ATX
Motherboard chipset: AMD B650 Express
Motherboard chipset family: AMD
Component for: Server
Memory
Maximum internal memory: 32 GB
Supported memory clock speeds: 3600, 5200
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory voltage: 1.1 V
ECC сompatibility: ECC & Non-ECC
Supported memory clock speed (max): 5200 MHz
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 10 - 35 °C
Operating relative humidity (H-H): 20 - 90%
Weight & dimensions
Depth: 243.8 mm
Width: 243.8 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
TPM connector: Yes
ATX Power connector (24-pin): Yes
Number of COM connectors: 1
EPS power connector (8-pin): Yes
BIOS
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 3.5
ACPI version: 6.4
Clear CMOS jumper: Yes
Storage controllers
RAID levels: 1, 10, 0
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 4
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 1
Serial ports quantity: 1
IPMI LAN (RJ-45) port: Yes
HDMI ports quantity: 1
Expansion slots
PCI Express x4 (Gen 4.x) slots: 1
Safety warning
Warnings: Do not open or disassemble the motherboard., Use only in a dry and well-ventilated area., The motherboard may contain electronic components hazardous to health - avoid direct contact.
