Processor
Processor manufacturer: Intel
Processor socket: LGA 1700
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3, Intel® Core™ i5
Maximum number of SMP processors: 1
Graphics
Parallel processing technology support: Not supported
Features
Motherboard chipset: Intel B760
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Memory
Maximum internal memory: 96 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 2
Weight & dimensions
Width: 244 mm
Depth: 201 mm
Network
LAN controller: Dragon RTL8125BG
Wi-Fi: Yes (Requires antenna)
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
12V power connector (8-pin): Y
LED connector: Y
USB 2.0 connectors: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
TPM connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
RAID levels: 1, 0, 5, 10
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Number of audio jack connectors: 3
HDMI ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
WiFi-AP antenna jack: 2
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
