Processor
Processor socket: LGA 1700
Compatible processor series: Intel Core i9 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i3 12th Gen, Intel Core i5 12th Gen, Intel Core i9 14th Gen, Intel Core i3 13th Gen, Intel Core i7 13th Gen, Intel Core i7 12th Gen
Processor manufacturer: Intel
Graphics
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio chip: Realtek ALC897
Motherboard chipset: Intel B760
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Memory
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Unbuffered memory: Yes
Number of memory slots: 2
ECC сompatibility: Non-ECC
Maximum internal memory: 96 GB
Weight & dimensions
Width: 244 mm
Depth: 201 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
LAN controller: Dragon RTL8125BG
Internal I/O
Number of SATA III connectors: 4
RGB LED pin header: Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
USB 2.0 connectors: 2
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
BIOS
BIOS type: EFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 5, 10, 1
RAID support: Yes
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Line-in: Yes
USB 2.0 ports quantity: 2
VGA (D-Sub) ports quantity: 1
Microphone in: Yes
DisplayPort version: 1.4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 1
