Processor Compatible processor series: Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 Processor manufacturer: Intel Maximum number of SMP processors: 1 Processor socket: LGA 1700
Features Audio output channels: 7.1 channels Windows operating systems supported: Windows 10 x64, Windows 11 x64 Motherboard form factor: micro ATX Audio chip: Realtek ALC897 Motherboard chipset family: Intel Motherboard chipset: Intel B760
Memory Memory channels: Dual-channel Number of memory slots: 4 Memory slots type: DIMM Supported memory types: DDR5-SDRAM Maximum internal memory: 256 GB ECC сompatibility: Non-ECC
Weight & dimensions Depth: 244 mm Width: 244 mm
Network Ethernet LAN: Yes LAN controller: Realtek RTL8125-BG Wi-Fi: No Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O Front panel audio connector: Yes Thunderbolt headers: 1 TPM connector: Yes RGB LED pin header: Yes USB 2.0 connectors: 6 ATX Power connector (24-pin): Yes Number of SATA III connectors: 4 CPU fan connector: Yes
BIOS BIOS type: UEFI AMI
Storage controllers Supported storage drive interfaces: M.2, SATA III Supported storage drive types: HDD & SSD
Rear panel I/O ports Ethernet LAN (RJ-45) ports: 1 USB 2.0 ports quantity: 2 Line-in: Yes Microphone in: Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3 DisplayPorts quantity: 1 PS/2 ports quantity: 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1 DisplayPort version: 1.4 HDMI ports quantity: 1
