Processor
Maximum number of SMP processors: 1
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5
Processor manufacturer: Intel
Processor socket: LGA 1700
Features
Motherboard chipset: Intel B760
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Memory
Memory channels: Dual-channel
Memory slots type: DIMM
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
LAN controller: Dragon RTL8125BG
Wi-Fi standards: 802.11g, 802.11a, Wi-Fi 6E (802.11ax), 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Bluetooth version: 5.3
Bluetooth: Yes
Internal I/O
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
TPM connector: Yes
CPU fan connector: Yes
RGB LED pin header: Yes
USB 2.0 connectors: 2
Front panel audio connector: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Microphone in: Yes
DisplayPorts quantity: 1
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
PS/2 ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
PCI Express x4 (Gen 1.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 1
