Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: ATX
Motherboard chipset: AMD B850
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Memory
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
ECC сompatibility: ECC
Maximum internal memory: 256 GB
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
LAN controller: Dragon RTL8125BG
Internal I/O
TPM connector: Yes
RGB LED pin header: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 4
EPS power connector (8-pin): Yes
USB 3.2 Gen 2x2 connectors: 1
CPU fan connector: Yes
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 10, 1
RAID support: Yes
Rear panel I/O ports
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 6
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage.
