Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
HDCP: Yes
HDCP version: 2.3
Features
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset: AMD B850
Audio chip: Realtek ALC897
Motherboard chipset family: AMD
Memory
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Wi-Fi standards: 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.4
LAN controller: Dragon RTL8125BG
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Wi-Fi: Yes
Ethernet LAN: Yes
Internal I/O
Number of chassis fan connectors: 3
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
TPM connector: Yes
CPU fan connector: Yes
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Line-in: Yes
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 2
