Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
Certification: FCC, CE, ErP/EuP
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio output channels: 7.1 channels
Product colour: White
Motherboard form factor: ATX
Audio chip: Realtek ALC4082
Motherboard chipset family: AMD
Motherboard chipset: AMD B850
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Number of memory slots: 4
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, 802.11b
Wi-Fi: Yes
LAN controller: Dragon RTL8125BG
Bluetooth version: 5.4
Bluetooth: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of SATA III connectors: 4
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
12V power connector: Yes
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 3
ATX Power connector (24-pin): Yes
Number of EPS power connectors (8-pin): 2
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
USB 3.2 Gen 2x2 connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
Number of storage drives supported: 8
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 1, 0, 10
Supported storage drive types: HDD & SSD
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB connector type: USB Type-C, USB Type-A
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
HDMI ports quantity: 1
WiFi-AP antenna jack: 2
USB 2.0 ports quantity: 4
S/PDIF out port: Yes
HDMI version: 2.1
Microphone in: Yes
Headphone outputs: 2
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 4
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
4th M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
4th M.2 largest key size: 2280
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 highest PCI Express generation: 4.0
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty.
