Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Certification: FCC, CE, ErP/EuP
Features
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Product colour: Black
Motherboard form factor: micro ATX
Motherboard chipset: AMD B850
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Unbuffered memory: Yes
Maximum internal memory: 256 GB
ECC сompatibility: ECC & Non-ECC
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
USB 2.0 connectors: 2
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
ATX Power connector (24-pin): Yes
Number of EPS power connectors (8-pin): 1
EPS power connector (8-pin): Yes
TPM connector: Yes
RGB LED pin header: Yes
12V power connector: Yes
CPU fan connector: Yes
Number of chassis fan connectors: 3
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes
Number of storage drives supported: 7
Rear panel I/O ports
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C, USB Type-A
DisplayPorts quantity: 1
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Line-in: Yes
HDMI version: 2.1
Microphone in: Yes
HDMI ports quantity: 1
Headphone outputs: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
3rd M.2 largest key size: 2280
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 3
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x4 (Gen 4.x) slots: 1
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
