Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
Maximum resolution: 3840 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Certification: FCC, CE, ErP/EuP
Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset family: AMD
Audio chip: Realtek ALC1220
Motherboard form factor: micro ATX
Motherboard chipset: AMD B850
Product colour: White
Memory
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
ECC сompatibility: ECC & Non-ECC
Number of memory slots: 4
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
LAN controller: Dragon RTL8125BG
Bluetooth: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), 802.11g, 802.11b
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.4
Wi-Fi: Yes
Internal I/O
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
CPU fan connector: Yes
USB 2.0 connectors: 2
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
TPM connector: Yes
RGB LED pin header: Yes
12V power connector: Yes
Number of RGB LED pin headers: 1
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
M.2 standoff included: Yes
Antenna included: Yes
Screws included: Yes
Storage controllers
RAID levels: 10, 0, 1
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes
Number of storage drives supported: 7
Rear panel I/O ports
USB connector type: USB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
Microphone in: Yes
Line-in: Yes
WiFi-AP antenna jack: 2
Headphone outputs: 3
Expansion slots
Number of M.2 (M) slots: 3
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x4 (Gen 4.x) slots: 1
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
