Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
HDCP: Yes
Certification: FCC, CE, ErP/EuP
Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Product colour: Black
Motherboard chipset family: AMD
Motherboard chipset: AMD B850
Audio chip: Realtek ALC897
Memory
Memory slots type: DIMM
ECC сompatibility: ECC & Non-ECC
Maximum internal memory: 128 GB
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Number of memory slots: 2
Weight & dimensions
Width: 244 mm
Depth: 226 mm
Network
LAN controller: Dragon RTL8125BG
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
MU-MIMO: Yes
Mobile network connection: No
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth: Yes
Bluetooth version: 5.2
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel audio connector: Yes
Number of EPS power connectors (8-pin): 1
12V power connector: Yes
EPS power connector (8-pin): Yes
CPU fan connector: Yes
RGB LED pin header: Yes
TPM connector: Yes
USB Type-C ports quantity: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 1, 0, 10
RAID support: Yes
Rear panel I/O ports
USB 2.0 ports quantity: 2
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Line-in: Yes
Microphone in: Yes
HDMI ports quantity: 1
HDMI version: 2.1
Audio output: 3.5 mm
Expansion slots
PCI Express x1 (Gen 4.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (E) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 2
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste.
