Technical details
Compliance certificates: CE, Federal Communications Commission (FCC)
Sustainability certificates: ErP
Processor
Compatible processor series: Intel Core Ultra (Series 2)
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Graphics
High Dynamic Range (HDR) supported: Yes
HDCP: Yes
Parallel processing technology support: Not supported
HDCP version: 2.3
Features
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset: Intel B860
Component for: PC
Product colour: White
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Memory
Supported memory clock speeds: 5600, 8666 MHz, 4400, 6800, 6533, 4800
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Supported memory clock speed (max): 8666 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 305 mm
Width: 244 mm
Network
Ethernet LAN: Yes
LAN controller: Dragon RTL8125BG
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), 802.11g, 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Bluetooth version: 5.4
Ethernet interface type: Gigabit Ethernet, Fast Ethernet, 2.5 Gigabit Ethernet
Internal I/O
Number of EATX power connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 9
12V power connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
ATX Power connector (24-pin): Yes
Number of water pump connectors: 1
Front panel audio connector: Yes
Number of chassis fan connectors: 4
Number of SATA III connectors: 4
RGB LED pin header: Yes
USB 2.0 connectors: 8
Front panel connector: Yes
CPU fan connector: Yes
Number of CPU fan connectors: 2
TPM connector: Yes
BIOS
BIOS memory size: 256 Mbit
BIOS flashback button: Yes
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Screws included: Yes
M.2 standoff included: Yes
Storage controllers
RAID support: Yes
Supported storage drive interfaces: PCI Express 5.0, M.2, SATA III
RAID levels: 10, 1, 5, 0
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 2.0 ports quantity: 2
HDMI version: 2.1
WiFi-AP antenna jack: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Line-in: Yes
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
HDMI ports quantity: 1
Expansion slots
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 2280
3rd M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 1
3rd M.2 highest PCI Express generation: 4.0
Processor special features
Intel Extreme Memory Profile (XMP): Yes
