Processor
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Graphics
HDCP: Yes
Features
Product colour: Black
Audio chip: Realtek ALC1220
Motherboard chipset family: Intel
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel B860
Motherboard form factor: ATX
Component for: PC
Memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Supported memory clock speed (max): 8666 MHz
ECC сompatibility: Non-ECC
Unbuffered memory: Yes
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11b, 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Bluetooth version: 5.3
LAN controller: Killer E3100G
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
Number of CPU fan connectors: 2
CPU fan connector: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
TPM connector: Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 5
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
Packaging content
Antenna included: Yes
Cables included: SATA
Storage controllers
RAID levels: 1, 10, 0, 5
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Microphone in: Yes
Thunderbolt ports quantity: 1
DisplayPort version: 1.4
S/PDIF out port: Yes
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 2.0 ports quantity: 3
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
