Processor
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Graphics
Graphics card family: Intel
On-board graphics card: Yes
Features
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard chipset: Intel B860
Motherboard form factor: ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64
Memory
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Number of memory slots: 4
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Bluetooth: Yes
LAN controller: Dragon RTL8125BG
Bluetooth version: 5.3
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11g, 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Ethernet LAN: Yes
Internal I/O
USB 2.0 connectors: 2
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
RGB LED pin header: Yes
TPM connector: Yes
CPU fan connector: Yes
Number of chassis fan connectors: 4
Number of CPU fan connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 5, 1, 10
RAID support: Yes
Rear panel I/O ports
DisplayPorts quantity: 1
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
HDMI ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
