Technical details
Compliance certificates: CE, Federal Communications Commission (FCC)
Processor
Supported processor sockets: LGA 1851
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Graphics
HDCP version: 2.3
Maximum resolution: 3840 x 2160 pixels
HDCP: Yes
High Dynamic Range (HDR) supported: Yes
Parallel processing technology support: Not supported
Features
Product colour: Black
Motherboard chipset: Intel B860
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Audio chip: Realtek ALC897
Memory
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Number of memory slots: 4
Unbuffered memory: Yes
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8666 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Bluetooth: Yes
LAN controller: Dragon RTL8125BG
Bluetooth version: 5.4
Ethernet interface type: Fast Ethernet, 2.5 Gigabit Ethernet, Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Wi-Fi: Yes
Internal I/O
Number of SATA III connectors: 4
Number of chassis fan connectors: 4
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
CPU fan connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of EPS power connectors (8-pin): 2
Number of water pump connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID levels: 1, 0, 10, 5
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
RAID support: Yes
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports
Line-in: Yes
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
WiFi-AP antenna jack: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
USB connector type: USB Type-C, USB Type-A
Headphone outputs: 3
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
3rd M.2 largest key size: 2280
1st M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
3rd M.2 highest PCI Express generation: 4.0
