Processor
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Graphics
Graphics card family: Intel
On-board graphics card: Yes
Graphics card: Intel Iris Xe Graphics
Features
Audio output channels: 7.1 channels
Motherboard chipset: Intel B860
Windows operating systems supported: Windows 11 x64
Motherboard form factor: mini ITX
Audio chip: Realtek ALC1220
Component for: PC
Motherboard chipset family: Intel
Memory
Memory slots type: DIMM
Number of memory slots: 2
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
ECC сompatibility: Non-ECC
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Bluetooth version: 5.3
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
LAN controller: Dragon RTL8125BG
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of CPU fan connectors: 1
Number of chassis fan connectors: 1
Number of SATA III connectors: 3
USB 2.0 connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
BIOS
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
RAID levels: 0, 1, 5
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Thunderbolt ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
S/PDIF out port: Yes
Microphone in: Yes
USB 2.0 ports quantity: 1
HDMI ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 2
