Processor
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Graphics
Graphics card family: Intel
On-board graphics card: Yes
Features
Audio chip: Realtek ALC897
Motherboard chipset: Intel B860
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Motherboard form factor: mini ITX
Motherboard chipset family: Intel
Memory
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 2
Weight & dimensions
Width: 170 mm
Depth: 170 mm
Network
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
LAN controller: Dragon RTL8125BG
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11b
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth: Yes
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 1
Number of EPS power connectors (8-pin): 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel audio connector: Yes
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 1
CPU fan connector: Yes
USB 2.0 connectors: 1
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
RAID levels: 5, 1, 0, 10
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 2
Microphone in: Yes
Line-in: Yes
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 1
Safety warning
Warnings: Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics., In case of installation problems, contact a qualified service technician.
