Processor
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Certification: FCC, CE, ErP/EuP
Features
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Motherboard chipset: Intel B860
Windows operating systems supported: Windows 11 x64
Memory
Maximum internal memory: 128 GB
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Weight & dimensions
Depth: 211 mm
Width: 244 mm
Network
Bluetooth: No
LAN controller: Realtek 8111H
Ethernet LAN data rates: 10,100,1000 Mbit/s
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
Number of water pump connectors: 1
Number of RGB LED pin headers: 1
Number of CPU fan connectors: 1
Number of chassis fan connectors: 2
Number of USB 3.2 Gen 2 Type-C ports : 1
12V power connector: Yes
CPU fan connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
RAID levels: 0, 5, 1, 10
RAID support: Yes
Rear panel I/O ports
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C, USB Type-A
Flashback BIOS button: Yes
HDMI version: 2.1
Antennas quantity: 2
HDMI ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Expansion slots
Number of SATA III connectors: 4
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
Safety warning
Warnings: In case of installation problems, contact a qualified service technician., When disposing of the product, follow local regulations for the recycling of electronics., Do not open or modify the motherboard to prevent damage.
