Processor
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Graphics
HDCP: Yes
On-board graphics card: Yes
Features
Motherboard form factor: micro ATX
Audio chip: Realtek ALC1220
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Motherboard chipset: Intel B860
Product colour: Black
Windows operating systems supported: Windows 11 x64
Component for: PC
Memory
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 8666 MHz
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
Bluetooth: Yes
LAN controller: Killer E3100G
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Ethernet LAN: Yes
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 4
USB 2.0 connectors: 2
Number of chassis fan connectors: 4
CPU fan connector: Yes
Number of CPU fan connectors: 2
ATX Power connector (24-pin): Yes
TPM connector: Yes
Front panel audio connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 10, 0, 5
Rear panel I/O ports
DisplayPort version: 1.4
DisplayPorts quantity: 1
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Microphone in: Yes
Thunderbolt ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
