Processor
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Graphics
On-board graphics card family: Intel Iris Xe Graphics
HDCP: Yes
Certification: FCC, CE, ErP/EuP
Features
Audio chip: Realtek ALC897
Motherboard chipset: Intel B860
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Memory
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Number of memory slots: 2
ECC сompatibility: Non-ECC
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Weight & dimensions
Width: 244 mm
Depth: 218 mm
Network
LAN controller: Dragon RTL8125BG
Bluetooth: Yes
Ethernet LAN: Yes
MU-MIMO: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
12V power connector: Yes
Number of water pump connectors: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
RGB LED pin header: Yes
Number of chassis fan connectors: 2
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
USB 2.0 connectors: 2
Front panel audio connector: Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 10, 1, 0, 5
RAID support: Yes
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Antennas quantity: 2
Flashback BIOS button: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB connector type: USB Type-C, USB Type-A
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
Expansion slots
PCI Express x1 (Gen 4.x) slots: 1
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 1
