Features Motherboard form factor: micro ATX PC health monitoring: CPU, Fan Motherboard chipset: Intel C266 Motherboard chipset family: Intel
Memory Number of memory slots: 4 Maximum internal memory: 32 GB Supported memory types: DDR5-SDRAM Memory voltage: 1.1 V ECC сompatibility: ECC Supported memory clock speed (max): 4400 MHz
Operational conditions Storage temperature (T-T): -40 - 70 °C Operating temperature (T-T): 10 - 35 °C Storage relative humidity (H-H): 20 - 90%
Weight & dimensions Depth: 244 mm Width: 244 mm
Internal I/O ATX Power connector (24-pin): Yes TPM connector: Yes Peripheral (Molex) power connectors (4-pin): 1 Number of SATA III connectors: 8 USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2 USB 2.0 connectors: 3
BIOS BIOS type: AMI BIOS memory size: 256 Mbit ACPI version: 6.4 System Management BIOS (SMBIOS) version: 2.8
Rear panel I/O ports VGA (D-Sub) ports quantity: 1 Ethernet LAN (RJ-45) ports: 2 Serial ports quantity: 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
