Features Component for: Server PC health monitoring: Fan, Temperature, Voltage Product colour: Green, Grey Motherboard chipset family: AMD Motherboard chipset: AMD SoC
Memory Memory voltage: 1.1 V Supported memory types: DDR5-SDRAM Number of memory slots: 24 Memory slots type: DIMM Maximum internal memory: 12.3 TB Supported memory clock speeds: 4800 Memory slot pin count: 288
Operational conditions Operating relative humidity (H-H): 20 - 90% Operating temperature (T-T): -40 - 70 °C Storage temperature (T-T): 10 - 35 °C
Weight & dimensions Depth: 350 mm Width: 430 mm
Network Ethernet LAN: Yes Wi-Fi: No Ethernet interface type: Gigabit Ethernet LAN controller: Intel® I350
Internal I/O Number of chassis fan connectors: 6 Chassis intrusion connector: Yes Number of COM connectors: 1 Front panel connector: Yes ATX Power connector (24-pin): Yes USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS Clear CMOS button: Yes ACPI version: 6.4 System Management BIOS (SMBIOS) version: 3.5 BIOS type: UEFI AMI
Storage controllers Number of HDDs supported: 32 Number of storage drives supported: 34 Supported storage drive types: HDD & SSD Supported storage drive interfaces: SATA III
Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4 IPMI LAN (RJ-45) port: Yes VGA (D-Sub) ports quantity: 1 Ethernet LAN (RJ-45) ports: 2
