Processor
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Pentium®
Processor socket: LGA 1700
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Graphics
Maximum resolution: 7680 x 4320 pixels
Parallel processing technology support: Not supported
HDCP: Yes
Features
PC health monitoring: Voltage, CPU, Fan, Temperature
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Motherboard chipset: Intel H610
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 2
Memory channels: Dual-channel
Unbuffered memory: Yes
Supported memory clock speeds: 5600
Maximum internal memory: 96 GB
Weight & dimensions
Width: 220 mm
Depth: 193 mm
Network
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
LAN controller: Realtek 8111H
Wake-on-LAN ready: Yes
Ethernet LAN: Yes
Internal I/O
RGB LED pin header: Yes
12V power connector: Yes
Chassis intrusion connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 4
USB 2.0 connectors: 1
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 1
CPU fan connector: Yes
TPM connector: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID support: No
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
PS/2 ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI version: 2.1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Safety warning
Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
