Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
Maximum resolution: 3840 x 2160 pixels
HDCP: Yes
Certification: FCC, CE, ErP/EuP
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset family: AMD
Motherboard form factor: mini ITX
Audio chip: Realtek ALC1220
Product colour: Black
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
Memory
ECC сompatibility: ECC & Non-ECC
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Bluetooth version: 5.2
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth: Yes
LAN controller: Killer E3100G
Internal I/O
Number of RGB LED pin headers: 2
Number of CPU fan connectors: 1
Number of water pump connectors: 1
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
CPU fan connector: Yes
Number of chassis fan connectors: 1
ATX Power connector (24-pin): Yes
12V power connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 2
USB 2.0 connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Antenna included: Yes
Storage controllers
RAID levels: 1, 10, 0
Number of storage drives supported: 4
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
WiFi-AP antenna jack: 2
HDMI version: 2.1
USB connector type: USB Type-A, USB Type-C
Headphone outputs: 2
Line-in: Yes
Microphone in: Yes
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
S/PDIF out port: Yes
Expansion slots
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
