Processor
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Graphics
Maximum resolution: 7680 x 4320 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Certification: FCC, CE, ErP/EuP, CEC Tier II
Features
Windows operating systems supported: Windows 11 x64
Product colour: Black
Motherboard chipset: Intel Z890
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Motherboard chipset family: Intel
Audio chip: Realtek ALC4082
Memory
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
ECC сompatibility: Non-ECC
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Ethernet LAN: Yes
Wi-Fi: Yes
LAN controller: Realtek RTL8126, Killer E3100G
Bluetooth: Yes
Internal I/O
12V power connector: Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
RGB LED pin header: Yes
Number of chassis fan connectors: 4
Number of EPS power connectors (8-pin): 2
Number of water pump connectors: 1
Number of RGB LED pin headers: 4
Number of CPU fan connectors: 2
USB 3.2 Gen 2x2 connectors: 1
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel audio connector: Yes
USB 2.0 connectors: 2
BIOS
Clear CMOS button: Yes
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Screws included: Yes
M.2 standoff included: Yes
Storage controllers
Number of storage drives supported: 10
RAID levels: 0, 10, 5, 1
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Thunderbolt ports quantity: 2
WiFi-AP antenna jack: 2
HDMI version: 2.1
Line-in: Yes
USB connector type: USB Type-A, USB Type-C
USB 2.0 ports quantity: 2
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 2
Expansion slots
6th M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 4.x) slots: 1
4th M.2 largest key size: 2280
2nd M.2 largest key size: 2280
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
4th M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
5th M.2 highest PCI Express generation: 4.0
6th M.2 highest PCI Express generation: 4.0
5th M.2 largest key size: 2280
Number of M.2 (M) slots: 6
