Processor
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Graphics
Maximum resolution: 7680 x 4320 pixels
Parallel processing technology support: Not supported
HDCP: Yes
Certification: FCC, CE, ErP/EuP
Features
Motherboard chipset: Intel Z890
Product colour: Black
Audio chip: Realtek ALC4082
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Motherboard form factor: mini ITX
Windows operating systems supported: Windows 11 x64
Memory
Maximum internal memory: 128 GB
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Number of memory slots: 2
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 170 mm
Depth: 170 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8126
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 1
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 2
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 1
CPU fan connector: Yes
12V power connector: Yes
Number of chassis fan connectors: 1
USB 3.2 Gen 2x2 connectors: 1
Number of water pump connectors: 1
EPS power connector (8-pin): Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Antenna included: Yes
Cables included: SATA
Screws included: Yes
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 0, 5, 1, 10
Number of storage drives supported: 5
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C, USB Type-A
S/PDIF out port: Yes
Headphone outputs: 1
Thunderbolt ports quantity: 2
HDMI version: 2.1
Microphone in: Yes
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6
WiFi-AP antenna jack: 2
Expansion slots
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
3rd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
