Technical details
Compliance certificates: CE, Federal Communications Commission (FCC)
Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Graphics
HDCP: Yes
Maximum resolution: 7680 x 4320 pixels
Parallel processing technology support: Not supported
HDCP version: 2.3
High Dynamic Range (HDR) supported: Yes
Features
Motherboard form factor: ATX
Audio chip: Realtek ALC4082
Motherboard chipset family: AMD
Product colour: Black
Motherboard chipset: AMD X870
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Maximum internal memory: 256 GB
ECC сompatibility: ECC & Non-ECC
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Number of memory slots: 4
Unbuffered memory: Yes
Supported memory clock speed (max): 8000 MHz
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), 802.11g, Wi-Fi 4 (802.11n), 802.11b
Bluetooth: Yes
Ethernet interface type: 5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
Bluetooth version: 5.4
Ethernet LAN: Yes
LAN controller: Realtek RTL8126
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Internal I/O
CPU fan connector: Yes
TPM connector: Yes
Number of chassis fan connectors: 3
Number of SATA III connectors: 2
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of water pump connectors: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
12V power connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
RGB LED pin header: Yes
USB 3.2 Gen 2x2 connectors: 1
BIOS
BIOS type: UEFI AMI
BIOS flashback button: Yes
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID support: Yes
RAID levels: 0, 10, 1
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Number of storage drives supported: 6
Rear panel I/O ports
S/PDIF out port: Yes
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 7
USB connector type: USB Type-A, USB Type-C
Headphone outputs: 1
WiFi-AP antenna jack: 2
Microphone in: Yes
USB 2.0 ports quantity: 6
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB4 Gen 3x2 ports quantity: 2
Expansion slots
PCI Express x16 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 4
2nd M.2 highest PCI Express generation: 5.0
4th M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
4th M.2 largest key size: 2280
1st M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
