Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Features
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
Motherboard form factor: ATX
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Maximum internal memory: 256 GB
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Bluetooth: Yes
LAN controller: Dragon RTL8125BG
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11g, 802.11b, Wi-Fi 4 (802.11n)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
Number of CPU fan connectors: 2
Front panel audio connector: Yes
USB 2.0 connectors: 2
Number of EPS power connectors (8-pin): 2
EPS power connector (8-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 10, 1
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
HDMI ports quantity: 1
Line-in: Yes
USB 3.2 Gen 2x2 Type-C ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 3
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
