Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Graphics
HDCP version: 2.3
HDCP: Yes
Certification: - FCC, CE- ErP/EuP ready
Features
Audio chip: Realtek ALC4082
Motherboard chipset family: AMD
Motherboard chipset: AMD X870E
Audio output channels: 5.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory: 128 GB
Memory channels: Dual-channel
Unbuffered memory: Yes
Number of memory slots: 2
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Weight & dimensions
Depth: 267 mm
Width: 305 mm
Network
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Gigabit Ethernet, Fast Ethernet
LAN controller: Realtek RTL8126
Wi-Fi: Yes
Antenna type: 2x2
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, 802.11 axe, 802.11b, Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Internal I/O
RGB LED pin header: Yes
12V power connector: Yes
Number of SATA III connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of CPU fan connectors: 2
USB 2.0 connectors: 2
USB 3.2 Gen 2x2 connectors: 2
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 4
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
BIOS
Clear CMOS button: Yes
BIOS type: UEFI AMI
Packaging content
Antenna included: Yes
Storage controllers
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 1, 10
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 7
HDMI ports quantity: 1
S/PDIF out port: Yes
USB4 Gen 3x2 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
Expansion slots
PCI Express x16 (Gen 5.x) slots: 2
PCI Express x4 (Gen 4.x) slots: 1
