Processor Processor socket: LGA 1700 Maximum number of SMP processors: 1 Compatible processor series: Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 Processor manufacturer: Intel
Features Windows operating systems supported: Windows 10 x64, Windows 11 x64 Motherboard form factor: ATX Audio chip: Realtek ALC897 Audio output channels: 7.1 channels Motherboard chipset family: Intel Motherboard chipset: Intel Z790
Memory Memory channels: Dual-channel Number of memory slots: 4 ECC сompatibility: Non-ECC Supported memory types: DDR5-SDRAM Memory slots type: DIMM Maximum internal memory: 256 GB Unbuffered memory: Yes
Weight & dimensions Depth: 244 mm Width: 305 mm
Network Ethernet interface type: 2.5 Gigabit Ethernet Wi-Fi: No Ethernet LAN: Yes LAN controller: Dragon RTL8125BG
Internal I/O CPU fan connector: Yes Thunderbolt headers: 1 RGB LED pin header: Yes Front panel audio connector: Yes TPM connector: Yes ATX Power connector (24-pin): Yes USB 2.0 connectors: 1 Number of SATA III connectors: 4 USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
