Processor Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5 Maximum number of SMP processors: 1 Processor manufacturer: Intel Processor socket: LGA 1700
Features Motherboard chipset family: Intel Motherboard chipset: Intel Z790 Windows operating systems supported: Windows 10 x64, Windows 11 x64 Audio chip: Realtek ALC897 Audio output channels: 7.1 channels Motherboard form factor: ATX
Memory Memory slots type: DIMM Maximum internal memory: 128 GB Memory channels: Dual-channel Number of memory slots: 4 Supported memory types: DDR5-SDRAM Unbuffered memory: Yes
Weight & dimensions Width: 305 mm Depth: 244 mm
Network Ethernet interface type: 2.5 Gigabit Ethernet Ethernet LAN: Yes LAN controller: Killer E3100G Wi-Fi: No
Internal I/O CPU fan connector: Yes ATX Power connector (24-pin): Yes USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1 Number of SATA III connectors: 8 USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1 Thunderbolt headers: 1 TPM connector: Yes Front panel audio connector: Yes USB 2.0 connectors: 2
BIOS BIOS type: UEFI AMI
Storage controllers RAID support: Yes RAID levels: 0, 5, 1, 10 Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports Microphone in: Yes DisplayPorts quantity: 1 USB 2.0 ports quantity: 2 USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2 HDMI ports quantity: 1 DisplayPort version: 1.4 Headphone outputs: 1 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4 USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1 Ethernet LAN (RJ-45) ports: 1
