Processor
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5
Processor socket: LGA 1700
Maximum number of SMP processors: 1
Features
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z790
Motherboard form factor: ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Maximum internal memory: 128 GB
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Thunderbolt headers: 1
Front panel audio connector: Yes
Number of SATA III connectors: 8
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
TPM connector: Yes
CPU fan connector: Yes
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10, 5
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
PS/2 ports quantity: 1
Line-in: Yes
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Safety warning
Warnings: Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal.
