Processor
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
Graphics
Maximum resolution: 7680 x 4320 pixels
Certification: FCC, CE, ErP/EuP
Features
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Product colour: Black
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: Mini-ITX
Motherboard chipset: Intel Z790
Motherboard chipset family: Intel
Memory
Supported memory clock speed (max): 8600 MHz
Maximum internal memory: 96 GB
Number of memory slots: 2
Memory slots type: DIMM
Memory channels: Dual-channel
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 170 mm
Depth: 170 mm
Network
Wi-Fi standards: 802.11 axe, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 6E (802.11ax), 802.11b, Wi-Fi 4 (802.11n)
Bluetooth: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
Bluetooth version: 5.3
Wi-Fi: Yes
Internal I/O
USB Type-C socket on the front panel: Y
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 1
Number of SATA III connectors: 3
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of chassis fan connectors: 2
CPU fan connector: Yes
Front panel audio connector: Yes
12V power connector: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Antenna included: Yes
Cables included: SATA
Screws included: Yes
Storage controllers
RAID levels: 10, 0, 5, 1
RAID support: Yes
Number of storage drives supported: 5
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
SPDIF optical output: Y
MIC input: 1
Number of USB 3.2 Gen 2 Type-A ports: 1
DisplayPort version: 1.4
Line-out: Yes
USB connector type: USB Type-A, USB Type-C
WiFi-AP antenna jack: 2
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 2
