Processor
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Processor socket: LGA1851
Compatible processor series: Intel Core Ultra (Series 2)
Features
Motherboard chipset: Intel Z890
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: ATX
Motherboard chipset family: Intel
Audio chip: Realtek ALC1220
Audio output channels: 7.1 channels
Memory
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Intel Extreme Memory Profile (XMP) version: 3.0
Number of memory slots: 4
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Memory slots type: DIMM
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: IEEE 802.11ac, IEEE 802.11g, IEEE 802.11b, IEEE 802.11n, 802.11 axe, IEEE 802.11ax, IEEE 802.11a, IEEE 802.11be
Ethernet LAN: Yes
Wi-Fi frequency: 2,4 Ghz / 5 GHz / 6 GHz
Wireless statistics: Yes
LAN controller: Killer E3100G
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Front panel audio connector: Yes
RGB LED pin header: Yes
Number of SATA III connectors: 4
Thunderbolt headers: 1
8-pin power connector 12 V: 2
AIO pump fan connector: 1
ATX Power connector (24-pin): Yes
Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports : 1
USB 2.0 connectors: 2
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: 2
Pump connector: 1
Chassis fan connector (4-pin): 4
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA III 2 pcs., ARGB Splitter Cable x 1, Thermistor Cable x 1
Wi-Fi antenna: Yes
Motherboard: Yes
Storage controllers
RAID levels: 5, 0, 1, 10
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Headphone outputs: 1
USB 2.0 Type-A ports quantity: 2
SPDIF optical output: Y
Number of antenna connectors: 2
Number of Thunderbolt 4 USB-C ports: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 1
Certificates
Certificates: CE, FCC, ErP/EuP ready
