Processor
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Features
Audio output channels: 7.1 channels
Audio chip: Realtek ALC1220
Operating system architecture: 64-bit
Motherboard form factor: ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel Z890
Memory
Memory slots type: DIMM
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5 non-ECC
Number of memory slots: 4
Supported memory clock speed (max): 9066 MHz
Memory channels: Dual-channel
Network
Wi-Fi standards: 802.11 axe, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
MU-MIMO: Yes
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
Bluetooth version: 5.4
Internal I/O
CPU fan connector: Yes
Thunderbolt 4 ports quantity: 2
USB 2.0 connectors: 6
Front panel audio connector: Yes
RGB LED pin header: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 2x2 Type-C ports quantity: 1
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 8
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 2
BIOS
BIOS type: UEFI AMI
Storage controllers
Supported storage drive interfaces: Blazing M.2 (PCIe Gen5 x4), Hyper M.2 (PCIe Gen4 x4)
Rear panel I/O ports
Line-out: Yes
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Microphone in: Yes
Thunderbolt 4 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Number of USB 3.2 Gen 1 ports: 4
USB 2.0 connectors: 2
S/PDIF out port: Yes
External antenna connector: Yes, x 2
USB 3.2 Gen 2x2 Type-C ports quantity: 2
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
