Processor
Bluetooth: Yes
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Features
Audio output channels: 5.1 channels
Motherboard chipset: Intel Z890
Motherboard form factor: ATX
Motherboard chipset family: Intel
Audio chip: Realtek ALC4082
Memory
Maximum internal memory: 256 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Supported memory clock speed (max): 9600 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Wi-Fi standards: Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax)
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Wi-Fi: Yes
Ethernet interface type: 5 Gigabit Ethernet, 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 4
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
Number of chassis fan connectors: 4
RGB LED pin header: Yes
Number of water pump connectors: 1
USB 3.2 Gen 2x2 connectors: 1
Number of EPS power connectors (8-pin): 2
BIOS
BIOS type: UEFI AMI
Clear CMOS button: Yes
Storage controllers
RAID levels: 5, 10, 1, 0
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
S/PDIF out port: Yes
Thunderbolt ports quantity: 2
Microphone in: Yes
WiFi-AP antenna jack: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
4th M.2 largest key size: 2280
6th M.2 largest key size: 2280
5th M.2 highest PCI Express generation: 4.0
5th M.2 largest key size: 2280
6th M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
3rd M.2 largest key size: 2280
4th M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
