Processor
Processor socket: LGA1851RL-ILM
Processor manufacturer: Intel
Maximum number of SMP processors: 1
Compatible processor series: Intel Core Ultra (Series 2)
Intel® Turbo Boost Technology: 3.0
Features
Audio output channels: 7.1 channels
Graphics card: Intel Xe LPG
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel Z890
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Memory
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5 DIMM
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Number of memory slots: 4
Intel Extreme Memory Profile (XMP) version: 3.0
Memory speed (max): 9466 MHz
ECC сompatibility: Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Bluetooth: Yes
Wi-Fi standards: 802.11 ax, 802.11ac, 802.11 axe, 802.11n, 802.11g, 802.11a, 802.11b
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Killer E3100G
Wi-Fi: Yes
Wi-Fi frequency: 2,4 Ghz / 5 GHz / 6 GHz
Bluetooth version: 5.3
Wireless statistics: Yes
Internal I/O
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
TPM connector: Yes
CPU fan connector: 2
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
8-pin power connector 12 V: 2
Pump connector: 1
Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports : 1
Number of RGB LED pin headers: 1
AIO pump fan connector: 1
Termistora Header: Yes
Chassis fan connector (4-pin): 3
Number of addressable LED slots: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Antennas quantity: 2
Motherboard: Yes
Wi-Fi antenna: Yes
Cables included: Thermistor Cable x 1, SATA III 2 pcs., ARGB Splitter Cable x 1
Storage controllers
RAID levels: 1, 10, 5, 0
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPort version: 1.4
Line-out: Yes
USB 2.0 Type-A ports quantity: 2
SPDIF optical output: Y
Number of microphone inputs: 1
DisplayPort out quantity: 1
Number of antenna connectors: 2
Number of Thunderbolt 4 USB-C ports: 2
Expansion slots
Number of SATA III connectors: 4
Number of M.2 (M) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Certificates
Certificates: FCC, CE, ErP/EuP ready
