Design
Product colour: Blue, Black
Number of fans: 0 fan(s)
Housing material: Metal
LED indicators: Yes
DIN rail mounting: Yes
Wall mountable: Yes
Power
Power supply included: No
Redundant power supply (RPS) support: Yes
DC input voltage: 48 - 57 V
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 48 mm
Depth: 157 mm
Width: 120 mm
Network
MAC address auto-aging supported: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
Full duplex: Yes
Networking standards: IEEE 802.3x, IEEE 802.3af, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Cable types supported: Cat4, Cat3, Cat5
MAC address auto-learning supported: Yes
Auto MDI/MDI-X: Yes
10G support: No
Flow control support: Yes
Performance
Mean time between failures (MTBF): 300000 h
Packaging content
User guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Store-and-forward: Yes
Switching capacity: 1.6 Gbit/s
MAC address table: 2000 entries
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
