Design
Number of fans: 0 fan(s)
DIN rail mounting: Yes
Wall mountable: Yes
Product colour: Black, Blue
LED indicators: Yes
Power
Power supply included: No
DC input voltage: 48 - 57 V
Redundant power supply (RPS) support: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -40 - 85 °C
Weight & dimensions
Height: 48 mm
Width: 120 mm
Depth: 157 mm
Network
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-T
Full duplex: Yes
Cable types supported: Cat3, Cat4, Cat5
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3u
10G support: No
MAC address auto-aging supported: Yes
Flow control support: Yes
MAC address auto-learning supported: Yes
Performance
Mean time between failures (MTBF): 300000 h
Packaging content
User guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 4000 entries
Switching capacity: 16 Gbit/s
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
