Design
Product colour: Black, Blue
Wall mountable: Yes
LED indicators: Yes
Number of fans: 0 fan(s)
DIN rail mounting: Yes
Power
Power supply included: No
Redundant power supply (RPS) support: Yes
DC input voltage: 48 - 57 V
Operational conditions
Operating temperature (T-T): -40 - 85 °C
Storage temperature (T-T): -40 - 85 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Width: 120 mm
Depth: 157 mm
Height: 48 mm
Network
Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z, IEEE 802.3, IEEE 802.3ab
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Auto MDI/MDI-X: Yes
MAC address auto-aging supported: Yes
Cable types supported: Cat4, Cat3, Cat5, Cat5e
MAC address auto-learning supported: Yes
10G support: No
Flow control support: Yes
Performance
Mean time between failures (MTBF): 300000 h
Packaging content
User guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 16 Gbit/s
MAC address table: 4000 entries
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 8
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
