ASUS PRIME H610M-A D4-CSM Intel H610 LGA 1700 micro ATX

Processor
Compatible processor series: Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5, Intel® Celeron®, Intel® Pentium®
Processor manufacturer: Intel
Processor socket: LGA 1700
Maximum number of SMP processors: 1

Features
Motherboard chipset: Intel H610
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Component for: PC

Memory
Number of memory slots: 2
Supported memory clock speeds: 2400, 2800, 3000, 3200, 2666, 2133 MHz, 2933
Unbuffered memory: Yes
Maximum internal memory: 64 GB
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM, LPDDR3-SDRAM
ECC сompatibility: Non-ECC

Weight & dimensions
Height: 221 mm
Depth: 211 mm
Width: 244 mm

Network
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Wake-on-LAN ready: Yes

Internal I/O
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 2
RGB LED pin header: Yes
USB 2.0 connectors: 1
S/PDIF out connector: Yes
12V power connector: Yes
Front panel audio connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
TPM connector: Yes
Number of SATA III connectors: 4
Number of COM connectors: 1

BIOS
BIOS memory size: 128 Mbit
BIOS type: UEFI AMI

Packaging content
Cables included: SATA

Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD

Rear panel I/O ports
DisplayPort version: 1.4
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
HDMI version: 2.1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
PS/2 ports quantity: 2

Expansion slots
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1

Other features
Weight: 382 g

Logistics data
Harmonized System (HS) code: 84733020
