ASUS ROG STRIX B550-F GAMING AMD B550 Socket AM4 ATX

Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 3000 Series
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Maximum number of SMP processors: 1

Graphics
On-board graphics card: No
Parallel processing technology support: 2-Way CrossFireX

Features
Windows operating systems supported: Windows 10 Home x64, Windows 10 Enterprise x64, Windows 10 x64, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Pro, Windows 10 IoT Enterprise, Windows 10 Home, Windows 10 Education, Windows 10 Pro x64, Windows 10, Windows 10 IOT Core
Cooling type: Active
Audio output channels: 7.1 channels
Product colour: Black
PC health monitoring: CPU, Fan
Motherboard form factor: ATX
Motherboard chipset family: AMD
Motherboard chipset: AMD B550
Power source type: ATX

Memory
Memory slots type: DIMM
Supported memory types: DDR4-SDRAM
Number of memory slots: 4
Supported memory clock speeds: 3600, 2400, 2800, 3466, 4133, 4000, 3200, 2666, 3000, 4600 MHz, 3866, 4400, 2133
Maximum internal memory: 128 GB

Weight & dimensions
Depth: 244 mm
Height: 68 mm
Width: 305 mm

Network
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.0
Wi-Fi: No
Wake-on-LAN ready: Yes
LAN controller: Intel I225-V
Bluetooth: Yes

Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 3
Number of EATX power connectors: 1
CPU fan connector: Yes
12V power connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 6
Thunderbolt headers: 1
USB 2.0 connectors: 2

BIOS
BIOS type: UEFI AMI

Packaging content
Drivers included: Yes
Manual: Yes
Cables included: SATA

Storage controllers
RAID levels: 0, 1, 10
Number of HDDs supported: 6
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III

Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Headphone outputs: 1
Microphone in: Yes
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
DisplayPort version: 1.2
USB 2.0 ports quantity: 2
S/PDIF out port: Yes
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1

Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI slots: 7
PCI Express x1 (Gen 3.x) slots: 3
PCI Express slots version: 4.0, 3.0

Other features
Weight: 945 g

Logistics data
Harmonized System (HS) code: 84733020

Safety warning
Warnings: Avoid direct contact with sensitive electronic components., Dispose of according to local electro-waste regulations., Store away from water and sources of moisture.
