Processor
Processor family: Realtek
Processor cores: 4
Processor model: RTD1619B
Processor manufacturer: Realtek
Processor frequency: 1.7 GHz
Memory
Internal memory: 1 GB
Internal memory type: DDR4
Flash memory: 8000 MB
Design
Cooling type: Active
Chassis type: Tower
Product colour: Black
Number of fans: 1 fan(s)
LED indicators: Yes
Fan diameter: 12 cm
Power
AC input voltage: 100 - 240 V
Power consumption (typical): 22.8 W
Power supply unit (PSU) capacity: 65 W
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 70 °C
Weight & dimensions
Depth: 218 mm
Height: 165 mm
Weight: 1.57 kg
Width: 164 mm
Network
Ethernet LAN data rates: 1000, 100, 2500 Mbit/s
Supported network protocols: Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Wake-on-LAN ready: Yes
Ethernet LAN: Yes
DHCP server: Yes
iSCSI support: Yes
Jumbo frames support: Yes
Performance
Noise level: 19.7 dB
Web-based management: Yes
Security algorithms: HTTPS, SNMP, 256-bit AES, SSH
Type: NAS
Browser supported: Firefox, Chrome, Safari, Microsoft Edge
Snapshot: Yes
Backup function: Yes
Number of users: 4096 user(s)
Access Control List (ACL): Yes
System log: Yes
Device class: Home & Home Office
S.M.A.R.T. support: Yes
Software
Server operating systems supported: Windows Server 2003, Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012, Windows Server 2008 R2
Linux operating systems supported: Yes
Windows operating systems supported: Windows 10, Windows 11
Operating system installed: ADM
Operating system version: 5.0
Storage
RAID levels: 0, 1, JBOD
Number of storage drives supported: 4
RAID support: Yes
Supported storage drive types: HDD & SSD
Installed storage drive type: No
Storage drive sizes supported: 3.5"
Bad block scan: Yes
Online RAID migration: Yes
Storage drives installed: No
Total installed storage capacity: 0 TB
Supported file systems: HFS+, ext4, exFAT, FAT32, ext3, NTFS
Storage drive interface: Serial ATA
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB port: Yes
