Processor
Processor threads: 4
Processor model: N5105
Processor cores: 4
Processor boost frequency: 2.9 GHz
Processor frequency: 2 GHz
Processor manufacturer: Intel
Processor family: Intel® Celeron®
CPU configuration (max): 1
Processor cache: 4 MB
Memory
Flash memory: 8192 MB
Maximum RAM supported: 16 GB
Memory slots: 2
Internal memory type: DDR4
Memory clock speed: 2933 MHz
Internal memory: 4 GB
Memory form factor: SO-DIMM
Design
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Power
Power consumption (sleep): 0.81 W
AC input voltage: 100 - 240 V
Power consumption (typical): 38.3 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 174 mm
Depth: 230 mm
Height: 170 mm
Weight: 2.26 kg
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 10, 1000 Mbit/s, 2500, 100
Performance
System log: Yes
Number of users: 4096 user(s)
Backup features: Cloud
Device class: Home & Home Office
Share folder: Y
Backup function: Yes
Access Control List (ACL): Yes
Browser supported: Firefox, Chrome, Safari, Microsoft Edge
Noise level: 19.7 dB
Security algorithms: 256-bit AES
Type: NAS
Software
Operating system installed: ADM
Operating system version: 4.1
Server operating systems supported: Windows Server 2008, Windows Server 2022, Windows Server 2012, Windows Server 2003, Windows Server 2016, Windows Server 2019
Linux operating systems supported: Yes
Mac operating systems supported: Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 10.9 Mavericks, Mac OS X 10.14 Mojave, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 13.0 Ventura, Mac OS X 10.13 High Sierra, Mac OS X 12.0 Monterey, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion
Windows operating systems supported: Windows 8, Windows Vista, Windows 11, Windows XP, Windows 10, Windows 7
Storage
Installed storage drive type: No
Storage drive interface: M.2, Serial ATA III
Storage drive size: 2.5/3.5"
Total installed storage capacity: 0 TB
Hot-swap drive bays: Yes
Supported file systems: FAT32, BTRFS, ext3, NTFS, ext4, HFS+, exFAT
Number of storage drives supported: 16
Storage drives installed: No
RAID levels: 10, 0, 1, 6, 5
Supported storage drive types: HDD & SSD
RAID support: Yes
Ports & interfaces
USB port: Yes
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 2
HDMI version: 2.0b
