Processor
Processor lithography: 14 nm
CPU configuration (max): 1
Processor codename: Denverton
Processor model: C3538
Processor operating modes: 64-bit
Tjunction: 100 °C
Processor frequency: 2.1 GHz
Processor code: SR3L7
Processor threads: 4
Stepping: B1
Processor boost frequency: 2.1 GHz
PCI Express slots version: 3.0
Processor family: Intel Atom®
Processor package size: 34 x 28 mm
Processor cores: 4
Processor socket: BGA 1310
Processor manufacturer: Intel
Tcase: 87 °C
Processor cache: 8 MB
Conflict-Free processor: Yes
Thermal Design Power (TDP): 15 W
Maximum internal memory supported by processor: 256 GB
Processor cache type: Smart Cache
Memory
Memory clock speed: 2133 MHz
Internal memory: 8 GB
Internal memory type: DDR4
Memory form factor: SO-DIMM
Flash memory: 4 MB
Maximum RAM supported: 32 GB
Memory slots: 2
Design
Built-in display: Yes
Product colour: Black
Cooling type: Active
Display type: LCD
Chassis type: Tower
Number of fans: 2 fan(s)
Fan diameter: 12 cm
Power
AC input voltage: 100 - 240 V
Power supply location: Built-in
Power supply unit (PSU) capacity: 250 W
Power consumption (typical): 66.9 W
Number of power supply units: 1
Power consumption (HDD standby): 37.2 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Weight: 6.2 kg
Width: 293 mm
Height: 215.5 mm
Depth: 230 mm
Network
Wake-on-LAN ready: Yes
Ethernet LAN data rates: 10000 Mbit/s, 2500 Mbit/s
Ethernet LAN: Yes
iSCSI support: Yes
Load balancing system: Yes
Ethernet LAN data rate supported (max): 10000 Mbit/s
Dynamic DNS (DDNS): Yes
Wi-Fi: No
Jumbo frames support: Yes
Link aggregation: Yes
Performance
Security algorithms: SSH, 256-bit AES, SSL/TLS, HTTPS
Web-based management: Yes
Noise level: 22 dB
Type: NAS
Multilingual support: Yes
Backup features: iSCSI LUN, Cloud
Access Control List (ACL): Yes
Backup function: Yes
S.M.A.R.T. support: Yes
Browser supported: Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge
Snapshot: Yes
Share folder access right management: Yes
Built-in UPnP AV media server: Yes
Device class: Small & Medium Business
System log: Yes
Built-in iTunes server: Yes
Packaging content
Quick installation guide: Yes
Cables included: LAN (RJ-45), AC
Number of screws: 66
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology): No
Intel® Turbo Boost Technology: No
Maximum number of PCI Express lanes: 12
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Embedded options available: Yes
Intel Secure Boot: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel Secure Boot Technology version: 1.00
Intel® Secure Key: Yes
Memory types supported by processor: DDR4-SDRAM
Intel Virtualization Technology (VT-x): Yes
Intel Secure Key Technology version: 1.00
Intel® OS Guard: Yes
Execute Disable Bit: Yes
Intel QuickAssist Technology: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Software
Windows operating systems supported: Windows 10, Windows 8, Windows XP, Windows Vista, Windows 7
Mac operating systems supported: Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yosemite, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.15 Catalina
Server operating systems supported: Windows Server 2012, Windows Server 2003, Windows Server 2008
Linux operating systems supported: Yes
Operating system installed: ADM
Operating system version: 3.1
Storage
Supported storage drive interfaces: Serial ATA III
RAID levels: 6, 5, 0, JBOD, 10, 1
Supported storage drive types: HDD & SSD
RAID support: Yes
Online RAID migration: Yes
Supported file systems: ext4, BTRFS, FAT32, HFS+, exFAT, ext3, NTFS
Installed storage drive type: No
Storage drive capacity: 0 GB
Storage drives installed: No
Number of storage drives supported: 8
Number of M.2 (M & B) slots: 2
Storage drive sizes supported: 3.5", 2.5
Maximum supported storage capacity: 128 TB
Total installed storage capacity: 0 TB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB port: Yes
Certification: FCC, CE, VCCI, BSMI, C-TICK
Other features
Processor ARK ID: 97929
Logistics data
Harmonized System (HS) code: 84714100
