Processor
Processor cores: 4
Tcase: 87 °C
Processor model: C3538
Conflict-Free processor: Yes
Processor threads: 4
Processor manufacturer: Intel
Processor cache: 8 MB
Maximum internal memory supported by processor: 256 GB
Processor socket: BGA 1310
Thermal Design Power (TDP): 15 W
Processor cache type: Smart Cache
Processor operating modes: 64-bit
Processor code: SR3L7
CPU configuration (max): 1
Processor frequency: 2.1 GHz
Tjunction: 100 °C
PCI Express slots version: 3.0
Processor family: Intel Atom®
Stepping: B1
Processor lithography: 14 nm
Processor codename: Denverton
Processor package size: 34 x 28 mm
Memory
Maximum RAM supported: 64 GB
Internal memory: 8 GB
Memory clock speed: 2133 MHz
Flash memory: 4096 MB
Internal memory type: DDR4
Memory form factor: SO-DIMM
Memory slots: 2
Design
Chassis type: Tower
Display type: LCD
Number of fans: 2 fan(s)
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black
Built-in display: Yes
Power
Power consumption (HDD standby): 41.1 W
Power supply location: Built-in
Number of power supply units: 1
Power supply unit (PSU) capacity: 250 W
Power consumption (typical): 76.8 W
Redundant power supply (RPS) support: No
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 230 mm
Width: 293 mm
Height: 215.5 mm
Weight: 6.4 kg
Network
Dynamic DNS (DDNS): Yes
Ethernet LAN data rate supported (max): 10000 Mbit/s
WLAN adapter supported: Yes
Link aggregation: Yes
iSCSI support: Yes
Load balancing system: Yes
Ethernet LAN: Yes
DHCP server: Yes
Jumbo frames support: Yes
Ethernet LAN data rates: 2500, 1000 Mbit/s, 100, 10000 Mbit/s
Wake-on-LAN ready: Yes
Performance
Share folder access right management: Yes
Universal Plug and Play (UPnP): Yes
Disk scan: Yes
Device class: Home & Home Office
Share folder: Windows ACL
Built-in UPnP AV media server: Yes
Access Control List (ACL): Yes
Backup features: Cloud, iSCSI LUN
Multilingual support: Yes
Noise level (idle): 22 dB
System log: Yes
Built-in iTunes server: Yes
Number of users: 4096 user(s)
Snapshot: Yes
S.M.A.R.T. support: Yes
Backup function: Yes
Browser supported: Internet Explore 11+, FireFox, Chrome, Safari, Microsoft Edge
Reset button: Yes
Security algorithms: SSL/TLS, SSH, 256-bit AES, HTTPS
Type: NAS
Web-based management: Yes
Packaging content
Number of screws: 66
Cables included: AC, LAN (RJ-45)
Processor special features
Intel QuickAssist Technology: Yes
Execute Disable Bit: Yes
Intel® Secure Key: Yes
Memory types supported by processor: DDR4-SDRAM
Maximum number of PCI Express lanes: 12
Intel VT-x with Extended Page Tables (EPT): Yes
Intel Secure Boot Technology version: 1.00
Intel Secure Key Technology version: 1.00
Intel Virtualization Technology (VT-x): Yes
Intel® OS Guard: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Turbo Boost Technology: No
Intel Secure Boot: Yes
Embedded options available: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): No
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Software
Operating system version: 3.4
Mac operating systems supported: Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 12.0 Monterey, Mac OS X 10.9 Mavericks, Mac OS X 10.6 Snow Leopard, Mac OS X 11.0 Big Sur
Windows operating systems supported: Windows XP, Windows 10, Windows Vista, Windows 8, Windows 7
Other operating systems supported: Linux
Linux operating systems supported: Yes
Operating system installed: ADM
Server operating systems supported: Windows Server 2012, Windows Server 2003, Windows Server 2008
Storage
Supported file systems: FAT32, ext4, BTRFS, HFS+, ext3, NTFS, exFAT
Total installed storage capacity: 0 TB
Online RAID migration: Yes
Bad block scan: Yes
Online RAID expansion: Yes
Number of M.2 (M & B) slots: 2
Storage drive capacity: 0 GB
Storage drives installed: No
Installed storage drive type: No
Storage drive sizes supported: M.2, 2.5, 3.5"
Number of storage drives supported: 10
RAID levels: 0, 10, JBOD, 6, 1, 5
Supported storage drive interfaces: Serial ATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Ports & interfaces
USB port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 4
Certification: FCC, CE, VCCI, BSMI, C-TICK
Other features
Processor ARK ID: 97929
Logistics data
Harmonized System (HS) code: 84714100
