Processor
Processor manufacturer: Intel
Processor cache: 4 MB
CPU configuration (max): 1
Processor family: Intel® Celeron® N
Processor cores: 4
Processor model: N5105
Processor frequency: 2 GHz
On-board graphics card model: Intel® UHD Graphics
Memory
Flash memory: 8000 MB
Maximum RAM supported: 16 GB
Memory slots: 2
Memory clock speed: 2933 MHz
Internal memory type: DDR4
Internal memory: 4 GB
Memory form factor: SO-DIMM
Design
Chassis type: Desktop
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Display type: LCD
LED indicators: Yes
Built-in display: Yes
Cooling type: Active
Product colour: Black
Power
Power consumption (sleep): 0.88 W
Power supply location: External
Power consumption (typical): 35 W
Power supply unit (PSU) capacity: 90 W
AC input voltage: 100 - 240 V
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 170 mm
Depth: 230 mm
Height: 185.5 mm
Weight: 2.94 kg
Network
iSCSI support: Yes
Ethernet LAN: Yes
Jumbo frames support: Yes
Dynamic DNS (DDNS): Yes
Wake-on-LAN ready: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100, 2500
Performance
Device class: Home & Home Office
Universal Plug and Play (UPnP): Yes
System log: Yes
S.M.A.R.T. support: Yes
Backup features: Cloud
Backup function: Yes
Access Control List (ACL): Yes
Browser supported: Firefox, Chrome, Safari, Microsoft Edge
Number of users: 4096 user(s)
Noise level: 17.6 dB
Type: NAS
Web-based management: Yes
Processor special features
Intel 64: Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Idle States: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Trusted Execution Technology: No
Enhanced Intel SpeedStep Technology: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Software
Mac operating systems supported: Mac OS X 12.0 Monterey, Mac OS X 10.9 Mavericks, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 11.0 Big Sur
Operating system installed: ADM
Operating system version: 4.1 Onwards
Linux operating systems supported: Yes
Server operating systems supported: Windows Server 2012, Windows Server 2019, Windows Server 2003, Windows Server 2016, Windows Server 2008
Windows operating systems supported: Yes
Storage
Storage drive capacity: 0 GB
Installed storage drive type: No
Number of M.2 (M & B) slots: 4
Total installed storage capacity: 0 TB
Storage drive sizes supported: M.2, 3.5", 2.5
Supported file systems: ext3, NTFS, FAT32, BTRFS, ext4, HFS+, exFAT
Number of storage drives supported: 4
Storage drives installed: No
Supported storage drive interfaces: M.2, Serial ATA
Supported storage drive types: HDD & SSD
RAID levels: JBOD, 6, 10, 1, 0, 5
RAID support: Yes
Ports & interfaces
HDMI version: 2.0b
USB port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
Concurrent connections: 512
Ethernet LAN (RJ-45) ports: 2
Logistics data
Harmonized System (HS) code: 84714100
